Product Specification and Size :
1):Engine: Yunnei
2):Rated Power: 62Kw
3)Rated Lift:2T
4):Operating Weight: 5500kg
5):Certification: CE ISO GS EMC
6):Dimension: 6100*2050*2900mm
DESCRIPTION OF Compact Mini Loader 2.8T
1. Four wheel double-line caliper disc braking system with a gas container in the back to guaranteea more safety and reliable operation.
2. Powerful engine: Weichai low rated rotate speed engine, strong power, energy conservation andenvironmental protection, Cummins engine, Shanachai engine is optional.
3. Easy to maintain: New desian of skeleton structure hood, Wide &ndash:opening hood makesservicing & maintenance of engine easier. Large distance between up and down articulatedboards creates large maintenance space, Exclusive dust-proof laver and sealed articulated pointsmake the loader more durable.
4. Hydraulic systems: adopt confluence of dual-pump confluence and difluence technology.rational use of engine power, reduce energy consumption effectively, Independent transmission oiand hydraulic oil cooling improve the hydraulic system stability.
5. Double iting am makes the broad view, Ariculated frame with smal turing radius makes the wheel loader fexible and convenient to operate
6. Optional spare parts chosen by users, such as the air conditioner, heat system, joystick, longer arms and so on.
7. Quick hitch for special needs such as the log grapple, fork, snow blade, grass fork, enarged bucket,rock bucket, loose materal bucket, side dump device, ect
DESCRIPTION Technical Parameters
| Item | Unit | LT918 |
| Rated load | kg | 1800 |
| Operation weight | kg | 5300 |
| Bucket capacity | cbm | 0.9 |
| Bucket width | mm | 2000 |
| Dimension | mm | 6100*2050*2900 |
| Dumping reach | mm | 800 |
| Dumping height | mm | 3500 |
| Total cycling time | s | 8.5 |
| Engine power | kw | 65 |
| Engine | Yunnei | |
| Axle | Isuzu | |
| Control system | Pilot joystick |
