Product Description:
The assembly process of a loader mainly includes chassis articulation, power and dual variable system assembly, transmission system assembly, operating device assembly, accessory assembly, and circuit connection. Adopting industry-leading flexible assembly lines, optimizing process routes, and effectively improving assembly productivity.
Technical Parameters:
| Machine parameter | |
| item | argument |
| (MM)Minimum turning radius | 5850 |
| (°)Theoretical climb Angle | 35 |
| (KM)Maximum travel speed | 38 |
| (KM)Minimum travel speed | 8 |
| (MM)Maximum unloading height | 3700 |
| (S)No-load lifting time | ≤6 |
| (S)No-load descent time | ≤5 |
| (S)Unloaded time | ≤1.5 |
| (S)Ternary sum | ≤12.5 |
| (MM)wheelbase | 2850 |
| (MM)Discharge distance | 1000 |
| (°)Discharge Angle | 33.5 |
| Machine parameter | |
| item | argument |
| (MM)Body length | 7100 |
| (MM)Body width | 2350 |
| (MM)Body height | 3100 |
| (MM)Minimum ground clearance | 420 |
| (MM)Wheel track | 1685 |
| (KG)Rated load mass | 2500 |
| (KG)Machine weight | 8100 |
| (MM)The bucket is long, deep and high | 2240/700/1100 |
| (m³)Bucket capacity | 1.7 |
| (KN)Maximum rising power | 33 |
| (KN)Maximum tractive effort | 38 |
| (KN)Combined tractive force | 30 |
Applications:
Packing and Shipping:
packaging
The loader will be carefully packaged to ensure safe delivery to our customers. The packaging will include:
Heavy duty cardboard box
Protective foam liner
Plastic packaging
an instruction manual
Shipping:
We provide global transportation services for loaders. Our shipping options include:
Standard transportation
express
air transport
ocean shipping
The transportation cost will vary depending on the selected destination and transportation method.
The loader will be carefully packaged to ensure safe delivery to our customers. The packaging will include:
Heavy duty cardboard box
Protective foam liner
Plastic packaging
an instruction manual
Shipping:
We provide global transportation services for loaders. Our shipping options include:
Standard transportation
express
air transport
ocean shipping
The transportation cost will vary depending on the selected destination and transportation method.
FAQ:
- Q: What is the brand name of this product?
A: The brand name of this product is Jawell. - Q: What is the model number of this product?
A: The model number of this product is JW-RG-939 - Q: Where is this product manufactured?
A: This product is manufactured in Shandong, China. - Q: Does this product have CE certification?
A: Yes, this product is certified with CE. - Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1 unit.
